Daim ntawv thov
63mm Precision Hauv qab Mount Roj - Sau Cov Ntsuas Ntsuas Nrog Stainless Hlau Casetso siab rau hauv cov dej ntim dej thiab txhawb nqa cov khoom siv tsis zoo thiab lwm yam kev ntsuas los txo cov kev cuam tshuam ntawm lub zog pulsating lossis kev vibration los ntawm lub tshuab, kev sib xyaw roj ntim cov ntsuas siab feem ntau yog siv rau hydraulic system, high pressure water flow equipment, natural gas system, water purification equipment and other pressure measurement.
Tsis muaj
- Txoj kab uas hla: 60mm
- Ua hauj lwm siab: static load mus rau sab sauv txwv ntawm kev ntsuas 3/4, alternating load mus rau lub sab sauv txwv ntawm kev ntsuas 2/3, luv luv -lub sij hawm siab mus rau sab sauv txwv ntawm kev ntsuas
- Kev sib txuas xov: M14X1.5, PF (PT / NPT) 1/4
- Instrument damping kua: methyl silicone roj
- Caij nplooj ntoos hlav tube: tin phosphor bronze raj
- Cov khoom siv sib txuas: tooj liab alloy
- Movement: Alloy
- Khoom siv: SUS304
- Qhov rai: PC iav
Kev ua haujlwm
1.Nrog ib tug ntse hloov siab los yog vibration ib puag ncig.Plus ib puag ncig tiv thaiv ntaus ntawv yuav tsum tau ntxiv;
2. Thov tsis txhob rub lub plhaub ntsuas los ntawm txhais tes hauv kev teeb tsa lossis tshem tawm, yuav tsum siv tus ciaj ntswj rau kev teeb tsa;
3. Kev ntsuas siab yuav tsum yog kab rov tav lossis ntsug.
4. Kev ntsuas nrog tawg txaus ntshai, yooj yim rau crystallization, yooj yim solidication, corrosion kuj yuav tsum tau, koj yuav tsum siv tshwj xeeb nruab nrab ntsuas ntsuas.
5. Lub ntsuas ntsuas siab yuav tsum tau siv ntawm qhov ntsuas kub nruab nrab ntawm -35℃~ +70℃nrog cov av noo tsis tshaj 85% (ze rau qhov ntsuas kub qis tshaj yuav cuam tshuam rau kev ua haujlwm ntawm lub ntsuas)
|
Scale Unit |
Pa |
KPa |
MPa |
bar |
kgf/cm² |
atm kev |
mmHg |
Lbf/in² (psi) |
|
Pa |
1 |
0.001 |
0.000001 |
0.00001 |
0.00001 |
0.00001 |
0.0075 |
0.000145 |
|
KPa |
100 |
1 |
0.001 |
0.01 |
0.010197 |
0.00987 |
7.50062 |
0.14504 |
|
MPa |
1000000 |
1000 |
1 |
10 |
10.1972 |
9.86923 |
7500.62 |
145.038 |
|
bar |
100000 |
100 |
0.1 |
1 |
1.01972 |
0.98692 |
750.062 |
14.5038 |
|
kgf/cm² |
98066.5 |
98.0665 |
0.098067 |
0.980665 |
1 |
0.9678 |
735.556 |
14.2233 |
|
atm kev |
101325 |
101.325 |
0.101325 |
1.01325 |
1.03323 |
1 |
760 |
14.6959 |
|
mmHg |
133.322 |
0.1333 |
0.000133 |
0.00133 |
0.00136 |
0.00132 |
1 |
0.01934 |
|
Lbf/in² (psi) |
6894.76 |
6.89475 |
0.00689 |
0.06894 |
0.07031 |
0.06805 |
51.7151 |
1 |
Cim npe nrov: 63mm precision hauv qab mount roj- filling siab ntsuas, Tuam Tshoj 63mm precision hauv qab mount roj- filling siab ntsuas lwm tus neeg, Hoobkas
